RBICAB Fire Alarm Cables are engineered to deliver reliable and uninterrupted signal transmission for critical fire detection and alarm systems. Designed to meet stringent safety standards, these cables offer excellent performance in both commercial and industrial installations where fast, accurate communication can save lives and property.
Manufactured with high-quality copper conductors and insulated with low-smoke, halogen-free, and flame-retardant materials, RBICAB fire alarm cables ensure superior fire resistance and minimal toxicity during emergencies. They are specifically constructed to maintain circuit integrity during fire exposure, enabling alarm signals and emergency devices to function when needed most.
RBICAB cables are available in both shielded and unshielded configurations, making them ideal for various applications such as smoke detectors, emergency lighting, audio evacuation systems, sprinkler controls, and fire panels. The robust outer sheath provides exceptional durability, resistance to heat, moisture, chemicals, and mechanical impact. Their easy installation and flexibility make them suitable for conduits, raceways, and surface wiring in high-rise buildings, hospitals, shopping complexes, factories, data centers, residential towers, airports, and metro stations.
| Parameter | Specification |
|---|---|
| Brand | RBICAB |
| Conductor Material | 99.97% Pure Annealed Copper |
| Conductor Type | Solid / Stranded (Class 2 as per IEC 60228) |
| Available Sizes | 0.5, 0.75, 1.0, 1.5, 2.5 sq.mm (others on request) |
| Insulation Material | PVC / FRLS / HRFR / LSZH |
| Insulation Thickness | 0.6 mm to 0.8 mm |
| Core Identification | Red-Black, Red-White, Red (Single Core), Custom Colors |
| Number of Cores | 1C / 2C / 3C / 4C / 6C / 8C / 12C |
| Shielding (Optional) | Aluminium Mylar Tape with Tinned Copper Drain Wire |
| Outer Sheath Material | PVC (FR / FRLS / HRFR) / LSZH |
| Outer Sheath Color | Red (Standard), White / Black / Grey (Optional) |
| Sheath Thickness | 0.9 mm to 1.2 mm |
| Rated Voltage | 300/500V or 450/750V |
| Test Voltage | 2.0 kV for 1 minute |
| Temperature Range | -20°C to +85°C (PVC), -30°C to +105°C (LSZH) |
| Insulation Resistance | > 1 GΩ/km at 20°C |
| Fire Standards | IEC 60332-1, IEC 60332-3, IEC 60754, IEC 61034, BS 7629 / BS 6387 (optional), UL 1424 (optional) |
| Construction Types | Unshielded, Shielded, Armoured (Optional) |
| Applications | Fire Alarm Systems, Smoke/Heat Detectors, PA Systems, Emergency Lighting, Fire Panels, Sprinkler Systems |
